matic web Mesin Semi Otomatis IKAME Spider

Spesifikasi Mesin
Model : IKAME-SPIDER
All Dimension : 3820 mm x 2880 mm x 400 mm
Inner Dimension : 3040 mm x 2500 mm
Material : Hollo Full HDG (Full Hot Dip Galvanized)
Frame Finishing : Powder Coating
Cover : ACP (Aluminium Composite Panel) PVDF
Process : 5-step Semi Automatic Carwash
Power : 13.400 watt 380 V / 50 Hz
Water Use : 435 liter / car
Engine Speed : 4 minutes / car
Wash Estimate : ± 5 minutes / car
Wash Capacity : ± 12 unit / hour
Water Noozle : 14
Shampo Noozle : 8
Rail : 50 mm x 50 mm
Spesifikasi Under Chasis
Dimension : 800 mm x 500 mm x 250 mm
Rail : 30 mm x 30 mm
Nozzle : 3 Pcs
proses QTY Jumlah Proses  Total (Liter) Waktu Total Proses
Under Chasis 81 Liter 1 X 81 Liter 42 Detik 42 Detik
Bilas Air 177 Liter 2 X 354 Liter 65 Detik 130 Detik
Shampoo 20 Liter 1 X 20 Liter 65 Detik 65 Detik
Shampoo 20 Liter 237 Detik
Air 435 Liter 3,95 Menit
Listrik Qty  Total (Watt)
Kompresor Udara 2235 W 1 2235 W
Pompa VMP 10-20 9300 W 1 9300 W
Motor Penggerak 373 W 2 745 W
Motor Lengan 745 W 1 745 W
Total 13025 W
